Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication

  • Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication
  • Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication
  • Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication
  • Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication
Place of Origin Jiangsu China
Brand Name Jiangnan
Certification CE, RoHS, CCC,ISO
Model Number CAT6
Minimum Order Quantity 1 Roll(100m or 305m)
Price $0.01 - $2.00/meter
Packaging Details Customized logo(Min. order 100000 meters) Customized packaging(Min. order 100000 meters) Graphic customization(Min. order 100000 meters)
Supply Ability 50000meters/7days

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Computer And Other Internet Devices Conductor Type Stranded
Conductor Copper Core Length Customized Length
Brand Jiangnan Type Insulated
Conductor Material Copper Material Copper+HDPE
Sample Free Sample Color Blue, Grey, Green, Orange Yellow, Violet Or Customer Spec
High Light

Bare Ethernet Cable 305m

,

Cat6 Ethernet Cable 305m

,

Stranded ftp ethernet cable
Leave a Message
Product Description
Products Description
CAT6 UTP LAN CABLE ETHERNET CABLE
24/23 AWG copper wire insulated with Polyethylene. Two insulated conductors twisted together to form a pair and four such pairs seprated by a cross filler form the core unit jacketed with flame retardant PVC/LSZH. Enhanced performance cable enables delivering high speed network.

Multi-color (15 colors) optional, flame retardant, RoHS compliant Materials compile with RoHS requirement. Widely used in wiring of office computers, monitoring terminals, digital information terminals, etc. There are two specifications of 300m/box and 100m/box. Wire size: 4×2×24AWG, the outer diameter of the cable is greater than 6.2mm
Item
Utp CAT6 Ethernet Lan Cable
Conductor
Oxygen free copper
Version
CAT6
Shielding
UTP/FTP/SFTP
Insulation
HDPE
Jacket
PVC/PE
Number Of Conductor
4 Pairs
Certificates
CE, RoHS, CCC,ISO
Application
Computer and other Internet devices
Frequency(Mhz)
Insertion loss (dB/100m)
RL(dB)
NEXT(dB)
PSNEXT(dB)
ELFEXT(dB)
PSPELFEXT(dB)
ACR(dB)
PSACR(dB)
1
2.0
20.0
74.3
72.3
67.8
64.8
72.3
70.3
4
3.8
23.0
65.3
63.3
55.8
52.8
61.5
59.5
8
5.3
24.5
60.8
58.8
49.7
46.7
55.5
53.5
10
6.0
25.0
59.3
57.3
47.8
44.8
53.3
51.3
16
7.6
25.0
56.2
54.2
43.7
40.7
48.6
46.6
20
8.5
25.0
54.8
52.8
41.8
38.8
46.3
44.3
25
9.5
24.3
53.3
51.3
39.8
36.8
43.8
41.8
31.25
10.7
23.6
51.9
49.9
37.9
34.9
41.2
39.2
62.5
15.4
21.5
47.4
45.4
31.9
28.9
32.0
30.0
100
19.8
20.1
44.3
42.3
27.8
24.8
24.5
22.5
200
29.0
18.0
39.8
37.8
21.8
18.8
10.8
8.8
250
32.8
17.3
38.3
36.3
19.8
16.8
5.5
3.5
500
45.3
15.2
33.8
31.8
13.8
10.8
4.5
2.8
600
51
14.5
31.2
29.9
11.8
8.6
3.5
2.1



Product features
The transmission rate is up to 1000Mbps, and the transmission bandwidth is 350MHZ. The transmission of digital, voice, data and video signals to meet the high-end demand is especially suitable for all E level links and Cat.6 applications.

The tightness (tight) of the insulating layer and the conductor is greater than 45N/50mm, and the retreating rate of the core line is more than 100%.

The direction of the wire stranded wire is opposite to the direction of the cable stranded line, and the cable adopts 100% back twisting to ensure the stability and the straight character of the cable structure.

Coat color has 15 colors for choice, and from outside the box can clearly identify.

In the process of the printing, the length of each line can be intuitively known in the process of construction.



Cat5: older, slower

Category 5 cabling, also known as Cat5, is an older type of network cabling. Cat5 cables support theoretical speeds of 10Mbps and 100Mbps. You may be able to get gigabit speeds over Cat5 cables, especially if the cables are shorter, but it's not always guaranteed.

Since Cat5 is an older cable type, you probably won't see it in stores much, but you may have bought some with older routers, switches, or other networking equipment.

Cat5e: faster, less distracting

Category 5 Enhanced Cabling, also known as Cat5e, is an improvement over Cat5 cabling. It supports 1000 Mbps "gigabit" speeds, so theoretically it's faster than Cat5. It also reduces crosstalk, the interference that can sometimes be experienced between wires within a cable. These two improvements mean you're more likely to get fast, reliable speeds from Cat5e cabling compared to Cat5.

Cat6: Faster, but not super necessary

Category 6 cabling is the next step up from Cat5e and includes many more improvements. It has tighter specifications in terms of interference and is capable of speeds up to 10 Gb in some cases. You probably won't be using these speeds at home, and the additional interference improvements won't have a huge impact on regular use, so you don't really need to rush to upgrade to Cat6. However, if you're going to buy a new cable, you can do so too, as it's an improvement over its predecessor.

So which should you use?

It's important to note that your network speed is not the same as your internet speed. The chance to upgrade your cable won't make a difference to how quickly you can load Lifehacker or Facebook -- your internet speed will still be much slower than your network. However, if you're transferring files between computers (for example, if you're backing up to a NAS), using gigabit-compatible hardware can make things go much faster. Remember, you'll need more than cables -- to get gigabit speeds, you'll also need a gigabit-compatible router and a gigabit-capable network card in your computer. Most modern routers and cards already have these fast speeds, but if you have any older PCs or routers, they probably won't. Google your hardware model number to find out.



Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication 0
Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication 1
Customize
Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication 2
Application
Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication 3
Our Factory
Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication 4
Certifications
Stranded Cat5 Cat5e Utp Ftp Bare Ethernet Cable 305m Communication 5
FAQ
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.

2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.

3. What’s your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.

4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.

5. Does your company accept OEM production?
Yes, we do.
