Multicore Electrical Building Wire

Place of Origin Jiangsu China
Brand Name Jiangnan
Certification CE,CCC,SABS,TUV,RoHS
Model Number BV H05V-U H07V-U H07V-R
Minimum Order Quantity 1000 Meters
Price $1.80 - $2.50/ meter
Packaging Details Customized logo(Min. order 10000 meters) Customized packaging(Min. order 10000 meters) Graphic customization(Min. order 10000 meters)
Supply Ability 50000meters<7days

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model Number BV Application Heating
Conductor Type Stranded Product Name Twisted Electric Wires Blue/Red Wire Cable
Core Multicore Sheath PVC
Colors Black Red Blue Yellow Green Surface Soft Annealing Bright
Type Insulated Conductor Material Copper
Insulation Material PVC Insulation PVC/ PE/Rubber
Colour White BLACK Red Blue Yellow Diameter ODM Customized
Product Keywords Building Wire Cable MOQ 1000 Meters
High Light

Multicore Electrical Building Wire

,

Multicore aluminum electrical cable

Leave a Message
Product Description
Products Description

BV is a general-purpose single-core hard conductor unsheathed cable, and the implementation standard is GB/T 5023.3-2008.

Product name; BV general-purpose single-core unsheathed cable Rated voltage: ≤1.5mm2 300V/500V; ≥1.5m㎡; 450V/750V.
Conductor: 1 core, in line with the requirements stipulated in GB/T 3956-1997: Type 1 for solid conductors; Type 2 for stranded conductors.
Insulation: PVC/type C polyvinyl chloride mixture.
Logo color: red, white, blue, green, black, gray, brown...
Cross-sectional area: 0.5-1.0mm2 60227IEC05 BV; 1.5-240mm2 60227IEC01 BV.
Operating temperature: In normal use, the maximum temperature of the conductor is 70°C.
Reference standards: GB 5023--2008, IEC60227.
Packing specifications: 100m, 500m, 1000m.

Multicore Electrical Building Wire 0
Multicore Electrical Building Wire 1
We can customized the size according to your requirement
OEM service available based on official & legal authorization.
●Strict quality control system.
●Rapid delivery and feedback.
●Excellent quality with reasonable price.
●Professional teamwork service for you actively.
●Stock available, Free sample is available.
product name:
BV SERIES For House wiring/building wiring
Product color:
Red/Blue/Yellow/Green/Yellow-Green
product material:
PVC sheath, oxygen-free pure copper
Specifications:
Certification
CE,CCC,SABS,TUV,RoHS

Stranded Electrical Wires
300/500V:0.5mm~1mm
450/750V: 1.5mm~630mm
600/1000V:1.5mm~630mm
Product length:
50meters/roll ;100 meters/roll; Cut meters according to customer requirements
Standard
GB, IEC, can be customized American standard, European standard, Australian standard
Use range:
Fixed wiring with rated voltage of 450/750V and below and flexible installation wiring
Note:
The special types of fire-retardent,flame-resisting,low-fume and non-halogon as well as acid-alkaliproof for these cables may be supplied upon requests
Multicore Electrical Building Wire 2
Multicore Electrical Building Wire 3
Multicore Electrical Building Wire 4
Multicore Electrical Building Wire 5
More Products
Application
Multicore Electrical Building Wire 7
Company Information
Multicore Electrical Building Wire 8
Certifications
Multicore Electrical Building Wire 9
FAQ
1.What are your main products?
bare wires,power plant & electrical equipment wire and cable, control cable, electromagnetic wire, 35KV and below power cable,mining cable, Marine cable, flame retardant cables and fireproof cables, low smoke zero halogen cables, termite proof cable,environmental protection wire cable, steel tape armoured cable, etc

2.Can we have our logo or company name to be printed on your products or the package?
Yes, OEM & ODM order is warmly welcome and we have fully successful experience in OEM projects. What's more, our R&D team will give you the professional suggestions.

3.How does your company do regarding Quality Control?
1)All raw material we selected the high quality one.
2)Professional & Skilful workers care every details in handling the producing.
3)Quality Control Department specially responsible for quality checking in each process.

4.How does your company do regarding Quality Control?
Yes, we'd like to provide free samples for your reference, you only need bear exp ress fees.
